Simes S.3546.14 Microtechnospot im20wg8,5 18° gray

S.3546

MICROTECHNO SPOT

-TYPE

Projector device.

IP 65 protection rating

-CHARACTERISTICS OF THE MATERIALS

Highly resistant EN AB-47100 die-cast aluminum body

to oxidation.

Tumbling process to prepare for the painting phase.

A4 stainless steel screws with a high molybdenum content of 2.5-3%.

Silicone ricotta gaskets.

Extra-resistant double painting carried out in 3 phases:

1) BONDERITE treatment with chemical protection of the material

metal-free fluozirconium containing ceramic nanoparticles that

create a cohesive, inorganic, high density layer.

2) PRE-POLYMERISATION cycle with primer application

epoxy with characteristics of overpainting on the device and of

high resistance to oxidation thanks to the presence of zinc.

3) POLYMERIZATION cycle with the application of polyester powder

with high resistance to UV rays and atmospheric agents,

with resistance to salt spray test of 1500h.

Mechanical resistance of glass IK 06

The front protective glass is 4mm thick.

-LIGHTING PERFORMANCE

Optical reflector in 99.98% pure aluminium, turned, anodized and polished.

Yield 51%

-INSTALLATION AND MAINTENANCE

Access to the lamp compartment is achieved simply by removing the ring

front.

The projector is supplied with a graduated crown on both sides.

The connection to the power line is made via a divider.

This makes wall installation easy, as it can be fixed

base, carry out the wiring and only then position

the complete appliance.

-WIRING

Single entry for power cables with cable gland.

Insulation class: CLASS I

Available colors: ALUMINUM GRAY (cod.14), ANTHRACITE GREY

(code 24)

Weight: 1.57 kg

Glow wire test: 850°C

Lamps supplied only on request.
