Simes S.4524.19 Ruler 370 blue LED spot 2.2w 230v

S.4522.19

PROJECTING DIFFUSER RULER

-TYPE

Appearance of wall installation.

IP 65 protection rating

-MATERIAL CHARACTERISTICS

Polycarbonate structure.

Front in AISI 316L stainless steel, 3 mm thick.

Zinc alloy counter ring.

Preparation of the slime for preparation during the painting phase.

A4 stainless steel screws has a high molybdenum content 2.5-3%.

Silicone ricotta gaskets.

Extra resistant double painting carried out in 3 steps:

1) BONDERITE treatment with chemical protection of the materials

Fluozirconic private metallic content of ceramic nanoparticles and that

create a cohesive, inorganic, high-density layer.

2) PREPOLYMERIZED cycle with application from the bottom

possible with reliability characteristics of all devices and

Raise the resistance to the possible resistance due to the pressure of the zinc.

3) POLYMERIZATION cycle with application of polyester powder

with high resistance to UV rays and atmospheric agents,

with salt temperature test resistance of 1500h.

Mechanical resistance of glass IK 09

-LIGHTING PERFORMANCE

Diffused in methacrylate.

Very bright, with the lamp in the correct position.

Return --

-INSTALLATION AND HANDLING

The wall-mounting boxes are supplied with the appliances and

a wall wire must be installed.

The front ring is made of AISI 316L stainless steel with a

one click system, without the use of screws, allowing a design

captivating with great cleanliness of shape.

It does not appear and is also equipped with clips for installation in walls

plasterboard and false ceilings. The life of the wall must be be

between 5 and 30 mm: SHORT RULER hole 226 x 36 mm,

LONG RULER hole 356 x 36 mm.

-WIRING

Appears with cables, connectors and heat strings.

Insulation class: CLASS II

Color available: INOX (cod.19)

Weight: 0.89 kg

Glow wire test: 650°C

It appears to provide the complete LED circuit. with emission class

1 (CEI EN 60825-1:2003-02)
