Simes s 6280w 01 skill ton led930 white

Name: Simes s 6280w 01 skill ton led930 white
Brand: Simes Spa
SKU: 211107
Price: 151.19 EUR
Availability: InStock

Simes Spa -

- 44 -

- S.6280W.01 -

Brand: Simes Spa

Last items in stock

269.98€ -44% €151.19

Tax included

In Stock: 1/PZ

Condizione prodotto:Used

Description
Product Details

ROUND SKILL

Art. S.6280W

3000K LED MODULE

Technical Data Light Source

Light source type:	LEDs
Color temperature:	3000K
Source luminous flux:	1131lm
Luminaire luminous flux:	427lm
Source power:	6.6W
Total power absorbed by the appliance:	8.1W
Luminaire luminous efficiency:	53lm/W
ULR:	3%
CIE Flux Code:	39 73 93 97 100
Color rendering index:	CRI 90
Color match standard deviation:	MacAdam step 3

Technical data Power supply

Voltage (AC):	220-240Vac
Frequency (AC):	50/60Hz
Dimming:	PHASE CUT (L-C) (DALI2 possibility; PUSH with extra charge)
Inrush Current:	2A 50µsec
Max number of pieces for B16A type thermal magnetic switch:	50
Max number of pieces for C16A type thermal magnetic switch:	85
Overvoltage protection (between L-N):	1÷2kV
Overvoltage protection (between L/N-PE):	2kV

Technical Data Temperatures and Duration

LED lifespan:	L80 B10 70.000h Ta 25°C L80 B10 50.000h Ta 40°C
DEVICE lifespan:	min. 70,000h Ta 25°C min. 50,000h Ta 40°C
Performance ambient temperature:	Tq 25°C
Operating ambient temperature:	from -20°C to +50°C
Storage temperature:	from -20°C to +60°C

Technical Data Installation

Electrical insulation class:	THE
IP protection rating:	IP65
Impact resistance:	IK08
Weight:	1.4475Kg

PRODUCT DESCRIPTION

TYPE
Wall mounted fixture. IP 65 protection rating

CHARACTERISTICS OF THE MATERIALS
EN AB-47100 die-cast aluminum body with high resistance to oxidation. Tumbling process to prepare for the painting phase. A4 stainless steel screws with a high molybdenum content of 2.5-3%. Silicone gaskets annealed.
Extra-resistant double painting carried out in 3 phases:
1) BONDERITE treatment with chemical protection of metal-free fluozirconic material containing ceramic nanoparticles that create a cohesive, inorganic, high density layer. 2) PRE-POLYMERISATION cycle with application of the epoxy primer with characteristics of overpainting on the device and high resistance to oxidation thanks to the presence of zinc. 3) POLYMERIZATION cycle with the application of polyester powder with high characteristics of resistance to UV rays and atmospheric agents, with resistance to the salt spray test of 1200h. Mechanical resistance IK 08

LIGHTING PERFORMANCE
Diffuser in tempered and speckled glass. Light source, with fixed lamp position. Yield --

WIRING
Prepared for through-wiring with grommet for SKILL.
Insulation class: CLASS I
Available colors: White (cod.01), Aluminum gray (cod.14), Anthracite gray (cod.24) Weight: 1.4475 Kg Glow Wire test: --
Luminaires supplied complete with LED module

SKILL REGISTERED MODEL

This device is equipped with integrated LED modules. In case of damage or malfunction, contact the manufacturer to receive additional instructions on how to replace the LED module and related components. The LED module of this device cannot be handled by the end user (EU Regulation 874/2012).

This product contains a light source of energy efficiency class (EPREL - European Product Registry for Energy Labeling): C.

LED module designed in accordance with the current regulation of Lumen Maintenance (LM80) and Technical Memorandum (TM21), where the light quality is reliable for the life of 70,000 hours traceable to L80 B10 Ta 25°C (50,000 hours traceable to L80 B10 Ta 40°C). Appliance lifespan min. 70,000 hours Ta 25°C, min. 50,000 hours Ta 40°C. Performance ambient temperature Tq 25°C. Operating ambient temperature from -20°C to +50°C. Storage temperature from -20°C to +60°C.

ELECTRONIC EQUIPMENT SENSITIVE TO OVERVOLTAGE.
It is recommended to install "SPD" surge protection devices in the electrical system. Protective devices prevent the intensity of these phenomena, protecting the devices from the risk of being damaged and prolonging their life. Outdoor lighting fixtures are subject to all types of permanent, temporary or transient electrical disturbances. Such disturbances can create permanent damage or failures that compromise performance and life. The surge protection device (supplied by SIMES) is used to limit the destructive effect of these phenomena. For each lighting fixture, a protection device must be provided at a distance of no more than 10m. For correct coordination of protections, a protection device against overvoltages must also be provided inside the electrical power panel of the system (the choice of the latter is the responsibility of the designer and is not provided by SIMES).

Condition Used

UPC 44

MPN S.6280W.01
