Gewiss gw21074 monostable relay 230v ac 50/60hz 1p 1no/nc 10a(ac1) 4a(ac15) 250v 1 module white system black

Gewiss GW21074 - Monostable Relay 230V AC 50/60Hz, 1P, 1NO/NC, 10A (AC1), 4A (AC15), 250V, 1 Module, White System Black

Main features:

• Brand: Gewiss
• Model: GW21074
• Relay Type: Monostable
• Nominal Voltage: 230V AC
• Nominal Frequency: 50/60Hz
• Number of Poles: 1P
• Number of Normally Open (NO) Contacts: 1
• Number of Normally Closed Contacts (NC): 1
• Rated Current (AC1): 10A
• Rated Current (AC15): 4A
• Degree of Protection (IP): IP41
• Width: 24mm
• Height: 46mm
• Depth: 25mm

Description: The Gewiss GW21074 monostable relay is designed for the control of electrical circuits in residential, commercial and industrial applications. With a nominal voltage of 230V AC and a frequency of 50/60Hz, this relay offers reliable and versatile operation.

Compact and Modular Design: With a compact design and a 1-module format, the Gewiss GW21074 easily integrates into electrical distribution panels, taking up little space and allowing for easy installation.

Application Versatility: Featuring one normally open (NO) and one normally closed (NC) contact, this relay offers flexibility in controlling power and signaling circuits, enabling a wide range of applications.

Quality Materials and Reliability: Made with high quality materials, including copper contacts and an IP41 protection rating, the Gewiss GW21074 ensures reliable operation even in harsh environments.

Simple and Safe Installation: With an electrical connection via screw fitting, the installation of this relay is simple and safe, guaranteeing a stable and resistant connection over time.

Typical Applications: This relay is suitable for a variety of applications, including lighting systems, electric motors, alarm systems and much more.

Important Note: We recommend consulting the technical specifications provided by the manufacturer for further details on the characteristics and installation methods of the Gewiss GW21074.

With the Gewiss GW21074, you can control your electrical circuits with reliability and precision, ensuring safe and efficient operation of your electrical equipment.
